PANASONIC 1TR 3STAR INVERTER – KU12AKY

Brand : Panasonic
Tonnage Class (TR) : 1.0
Model [50Hz] : CS/CU-KU12AKY
Cooling Capacity Standard [Min. - Max.] (Btu/h) : 11765 [5303 - 12965]
Cooling Capacity Standard [Min. - Max.] (W) : 3450 [1555 - 3800]
ISEER : 3.95
Annual Power Consumption (kWh) : 676.64
Star Rating (★) : 3★
Electrical Data
Voltage (V-AC) : 230
Frequency (Hz) : 50
Phase (Φ) : Single Phase
Running Current (A) : 5.2
Power Input, Standard Cooling [Min. - Max.] (W) : 1145 [356 - 1546]
- Moisture Removal Rate (l/h) : 1.0
Moisture Removal Rate (Pt/h) : 2.1
Air Circulation (Indoor) (mᵌ/min) : 12.0
Air Circulation (Indoor) (ftᵌ/min) : 424
Dimensions of the Indoor Unit : Length (L) (cm) 87.0 - Breadth (B) (cm) 21.1 - Height (H) (cm) 29.0
Dimensions of the Outdoor Unit : Length (L) (cm) 67.2 - Breadth (B) (cm) 24.0 - Height (H) (cm) 52.0
Noise Level : Indoor (H/Q) [dB-A] 45/36 - Outdoor [dB-A] 53
Net Weight : IDU [ODU] (kg) 9[22] - IDU [ODU] (lb) 20[49]
Gross Weight : IDU [ODU] (kg) 10[25.5] - IDU [ODU] (lb) 22[56]
Refrigerant : R-32
Operating Temp. Range (℃) : 16 ~ 52
Operating Volt. Range (V) : 145-285
